Trovac 10A 240V Central Vac...
$79.99
Product details
This is a 10-amp, 240-volt central vacuum control board, stocked under SKU ELECIR903V. It includes a wire connection point, a speaker connection, and an onboard LED indicator, the electrical rating that sets it apart from the other board in Trovac's control board range.
- Part: ELECIR903V
- Rating: 10 A, 240 V
- Connections: wire and speaker
- Indicator: onboard LED
Control boards in a central vacuum power unit are matched to the motor's electrical rating, not swapped between units of different voltage or amperage, so confirm the rating stamped on your existing board or unit before ordering rather than going by model name alone, since two units in the same family can still be built for different supplies.
A board that no longer holds the unit's LED or drops the speaker signal while the motor itself still runs is the usual sign this component, rather than the motor, needs replacing, since the LED and speaker circuit run off the board and not off the motor windings directly.
