Trovac Assembled Peripheral...
$164.99
Product details
A central vacuum system's motor is what turns household debris into airflow, and this Trovac build supplies that motor as an assembled, ready-to-wire unit. Part FMCY036102 is a two-stage peripheral bypass motor rated at 570 airwatts on 120 V.
The peripheral bypass layout pulls cooling air for the motor from a channel around the fan rather than the suction path itself, so the airstream carrying dust and grit never runs through the windings. At 570 airwatts this motor sits in Trovac's mid-to-upper range, suited to systems with more inlets or longer pipe runs than an entry-level unit. Motors in this class run continuously for as long as the system is in use, so a whine, a grind, or a motor that trips its thermal cutout more often than it used to is worth acting on before it fails outright and leaves the household without suction.
- Type: Peripheral bypass, 2-stage
- Rating: 120 V, 570 airwatts
- Build: Assembled, ready to install
Motor mounts, frame sizes, and lead connectors differ between central vacuum power units, so compare part FMCY036102 against your original motor or your unit's parts diagram before ordering, and reuse the mounting gasket only if it is still in good condition.
