Oreck Cord, Switch, and Han...
$79.99
Product details
Part 097561101 is a complete replacement kit for the Oreck 9000 series of commercial uprights, listed for the XL9300G. The handle grip, the switch, the lead cord and the main power cord all arrive together as one assembly, wired in the three-wire commercial configuration these machines use, so a repair that would otherwise mean sourcing four separate pieces becomes a single order and a single teardown.
That grouping matters on a machine that runs commercial hours, because these parts tend to wear out together after years of daily service. The cord frays where it leaves the handle, the switch loses its clean snap after thousands of cycles, and the grip cracks from the same hand pressure landing on the same spot shift after shift. Chasing each failure separately would mean stripping the handle down several times over the life of the machine; the kit resets all of it in one pass. On a route running several machines, it also standardizes the repair, since one part number covers the whole handle-end electrical set instead of a drawer of individual components.
Disconnect the machine from power completely before starting, and keep the old assembly within reach as a reference while fitting the new one. Match the cord's run from the motor housing up to the handle piece by piece rather than improvising a new path, and confirm every connection seats fully before the housing closes. Test the switch with the housing still open, so a loose connection shows itself while everything is still reachable. If the wiring inside the old handle shows scorching or heat damage rather than plain wear, have the rest of the circuit checked as well, since a cord kit cures worn parts but not whatever overheated the originals.
- Part: 097561101
- Includes: switch, lead cord, power cord, and handle grip
- Wiring: three-wire commercial configuration
- Fits: Oreck 9000 series commercial uprights, including the XL9300G
