Hayden Next Generation Supe...
$26.99
Product details
The Hayden Next Generation SuperValve is a direct connect inlet valve with a square door, finished in white, built for central vacuum systems that use a 110V powered receptacle at the inlet. Direct connect operation means the hose triggers the power nozzle the instant it is inserted, with no separate power cord needed at the tool end.
This is the kind of inlet installers reach for on a retrofit, when an older cord-dependent system is being upgraded to direct connect, or when a worn inlet with a failing door or receptacle needs a straight swap. A square door that no longer seats flush is one of the more common reasons suction drops at a single inlet while the rest of the system runs fine, since the gap lets air bleed in continuously between uses.
Confirm your existing wall box and receptacle wiring are compatible with a 110V direct connect inlet before ordering, since inlet mounting patterns and power requirements are not interchangeable across central vacuum brands.
A retrofit installation is usually the more involved half of the job, since it means opening up an existing wall box rather than working with a fresh rough-in. Take the time to confirm the wall box depth and wiring access are adequate for this valve before committing to the swap, particularly on older installations where box dimensions were not standardized.
- Part: 791790W, Hayden Next Generation SuperValve
- Finish: white, square door, 110V powered receptacle
- Use: direct connect inlet, power nozzle activates on hose insertion
- Replace when: the door no longer seats flush or the receptacle connection is unreliable
